5-2 ODU MOUNTING
NWD-107460-02E Installation
Notes
1. Do not use both small O-ring and large O-ring simultaneously.
2. O-ring size is different with frequency band as follows:
Position of
Large size
O-ring
Position of
Small size
O-ring
for Waveguide Connection
for Antenna Direct Mounting
ANDREW Antenna
Position of
Large size
O-ring
Position of
Small size
O-ring
RFS Antenna
for Waveguide Connection
for Antenna Direct Mounting
3
2
mm
35
mm
Large size O-ring for Antenna Direct Mounting
26-38 GHz Band
4
0m
m
10-11 GHz Band 13-23 GHz Band
4 mm
4 mm 4 mm
18/23 GHz Band 32/38 GHz Band
1
5.6m
m
Small size O-ring for Waveguide Connection
10.8
m
m
1.8 mm 1.8 mm
