NEC iPasolink 200 - V Polarization; H Polarization

ODU MOUNTING 5-17
Installation NWD-107460-02E
V Polarization
-
IR
Plate marked with V
Guide pin
UP
-
I
R
Plate marked with H
Guide pin
UP
H Polarization
V/H Polarization Conversion
13-38 GHz ODU
