NEC iPasolink 200 - Installation Kit Packing List of IDU and ODU for 1+0 System

PACKAGES 2-4 Installation NWD-107460-02E
Fig. 2-3 Installation Kit Packing List of IDU and ODU for 1+0 System
PS-S
SFP Module Connector
Lug (FG)
USB Connector
Modular Connector
D-Sub Connector (Female)
MDR Connector
Power Supply
Connector
FAN Unit
(Replaceable)
16E1-S
D-Sub Connector
MDR Connector
Power Supply Connector
AUX-S
STM1-S
SFP Module Connector
ODU (13-38 GHz)
N-P Connector
N-P Connector
ODU (6-11 GHz)
Lug (FG)
TNCP Connector
Lug (FG)
