CABLE TERMINATION 6-31
Installation NWD-107460-02E
(3) The gap of the connector body and clamp nut is confirmed.
(*) Gap: 2.2 to 2.7 mm
Note Do not remove the connector body tightened up once. When removing, it
is reworked from procedure 1 or a cable is exchanged.
Tools
• spanner (16 mm)
• torque spanner (16 mm)
• clearance gauge, measure
