10-2 ANTENNA ORIENTATION

NWD-107460-02E Installation

6 At each station, adjust the azimuth and elevation angle of the antenna alternately

so that the measured voltage becomes maximum,

Note The relation of the RX INPUT LEVEL versus RX LEVEL MON(V) is

shown below.

RX LEVEL MON vs RX INPUT LEVEL (Typical)

RX INPUT LEVEL [dBm]

-80

-70 -60 -50 -40 -30 -20

0.5

1.5

2.5

3.5

4.5

RX LEVEL MON [V]
