10-10 ANTENNA ORIENTATION
NWD-107460-02E Installation
Fig. 10-5 Location of Adjusting Nuts and Bolts (RFS C-Mount type bracket)
B. RFS C-Mount type bracket
Pole
Screw 2
Screw 3
Screw 1
Rotation
indicator
A. RFS SB1 type bracket
