CABLE TERMINATION 6-5
Installation NWD-107460-02E
3 Remove of braided wire, insulator.
(1) The insulator and an aluminum tape are cut along an end face of turned up
braided wire.
Note Do not damage the braided wire and the center conductor.
Aluminum tape
Insulator
Center conductor
