USER CODES
ASSIGNING EXTRA OPTIONS
assigned when programming the code or at any time later.
In NORMAL USER CODE PROGRAMMING mode, (Exclude
light is off), you can do the following:
Program Keypad Codes (see page 14).
Program Radio Codes (see page 72).
Program Access cards (see page 74).
View radio signal strength (see page 70).
In EXTRA OPTIONS mode, (Exclude light is on), you can assign
several powerful functions to each user code. See below.
To view and program the Extra Options:
1. Select a User Code (P201–P256E). The Exclude light is OFF.
2. Press EXCLUDE E. The Exclude light turns ON.
The following Extra Options can now be changed:
1E AREA 1 CODES. Assign/remove user codes to Area 1. (By
default all user codes are assigned to Area 1.
2E AREA 2 CODES. Assign/remove user codes to Area 2.
User codes can be assigned to Area 1, Area 2, both areas or
no areas.
An Area will not arm unless it has one or more zones assigned
to it (P45E, P46E).
If a code is not assigned to any Area/s, the code can be used
for special functions such as to trigger outputs.
3E ARM ONLY. User Codes 2–56 can be programmed to Arm but
not Disarm the panel. (See page 14).
4E . Enables selected user codes to
with or without the use of the arm key on the keypad.
In the case of radio codes the radio key OFF button will toggle
the armed state of the area assigned to the radio key.
If the User code is assigned to both AREA 1 and AREA 2.
If AREA 1 is already armed, then entering the code will disarm
AREA 1 - but arm AREA 2.
If the intention is to either ARM or DISARM both areas using this
code then ARM + [code] must be used first to arm both areas.
Once both are armed they can be disarmed.
If in Home mode, then the action is to exit Home mode.
Codes selected for Code Only Arming and not assigned to
any areas are automatically REX codes. See page 78.
5E RADIO CODE. Enables selected user codes as Radio Codes
for operation by Ness Radio Key or Radio Keypad. (Page 72
- how to program Radio Codes).
6E READER CODE 1. Enables user codes as Access Control
codes assigned to Reader 1. (Page 74 - Access Cards).
7E READER CODE 2. Enables user codes as Access Control
codes assigned to Reader 2. (Page 74 - Access Cards).
8E READER CODE 3. Enables user codes as Access Control
codes assigned to Reader 3. (Page 74 - Access Cards).
A user code can be assigned to any one, two or all three
access control readers.
9E ENABLE FOR AUTOTIME. Enables user codes for use by
AutoTime. (See page 69, Enable/Disable User Codes Via
AutoTimer).
USER CODE
OPTIONS TABLE
EXCLUDE+E toggles EXTRA OPTIONS MODE.
The Exclude light indicates this mode is on/off.
(Installer Program mode only)
USER
CODE
OPTION
NO.
KEYPAD
PIN
1E
AREA
1
CODE
2E
AREA
2
CODE
3E
ARM
ONLY
4E
"CODE
ONLY"
ARM
(REX
CODE)
5E
RADIO
CODE
6E
Reader
Code 1
7E
Reader
Code 2
8E
Reader
Code 3
9E
Au-
toTime
Code
1
(Master)
P201E 123
ON ON
2 P202E
ON
3 P203E
ON
4 P204E
ON
5 P205E
ON
6 P206E
ON
7 P207E
ON
8 P208E
ON
9 P209E
ON
10 P210E
ON
11 P211E
ON
12 P212E
ON
13 P213E
ON
14 P214E
ON
15 P215E
ON
16 P216E
ON
17 P217E
ON
18 P218E
ON
19 P219E
ON
20 P220E
ON
21 P221E
ON
22 P222E
ON
23 P223E
ON
24 P224E
ON
25 P225E
ON
26 P226E
ON
27 P227E
ON
28 P228E
ON
29 P229E
ON
30 P230E
ON
31 P231E
ON
32 P232E
ON
33 P233E
ON
34 P234E
ON
35 P235E
ON
36 P236E
ON
37 P237E
ON
38 P238E
ON
39 P239E
ON
40 P240E
ON
41 P241E
ON
42 P242E
ON
43 P243E
ON
44 P244E
ON
45 P245E
ON
46 P246E
ON
47 P247E
ON
48 P248E
ON
49 P249E
ON
50 P250E
ON
51 P251E
ON
52 P252E
ON
53 P253E
ON
54 P254E
ON
55 P255E
ON
56 P256E
ON
15
Ness D8x / D16x Control Panel – Installation Manual
