SPECIFICATIONS
Box dimensions ..................... 235w x 300h x 90d mm.
Plug pack ............................... 240V AC, output 17V AC@1.4A.
Power supply .........................13.8V DC @ 800mA.
Quiescent current draw ......... 80mA with 1 keypad.
Operating voltage .................. 9.5V– 14V DC.
Rechargeable battery............. 12 volt 7.0 Amp/hour Sealed Lead Acid.
Battery charging current ........ 350mA maximum, current limited.
Dynamic battery test .............. Backup battery is tested under load, hourly and on arming.
Fuses ......................................
500mA auto resetting / 12 volt auxiliary outputs.
200 mA auto resetting / strobe output.
INPUTS
Zones ..................................... 8 or 16 zone inputs. 2 x 24hr tamper inputs.
End of line resistor ................. Default 2200 Ohms (2.2k). Other values programmable.
Maximum keypads ................. 3.
RADIO Header ....................... Multi-pin connector for the Ness Radio Interface (100-200).
SERIAL Header ...................... Serial data port for data input.output and direct connect programming
using NessComms™ software.
READER Header .................... Multi-pin port for connecting up to 3 Ness proximity access card
readers.
OUTPUTS
Siren ....................................... On board siren driver with timed output .
Maximum 3 x 8 Ohm horn speakers.
Strobe ..................................... 12V DC timed output. Maximum 2 x 1 Watt strobe lights.
Reset ...................................... 12V DC timed output. Maximum 3 x 12V piezo screamers.
Equipment power output ....... 13.8V DC output for powering detectors and other equipment. Maxi-
mum 500mA.
AUX Header ...........................Multi-pin connector provides outputs Aux1, Aux2, Aux3, Aux4, 12V DC.
APPROVALS
EMC COMPLIANCE
EN 50130-4:1996 Part 4: Electromagnetic compatability. Electrostatic Discharge, Radiated RF
Immunity, Electrical Fast Transient/burst. Surge Immunity, Conducted RF Immunity, Voltage Dips and
Interruptions, Mains Supply Variations.
AS/NZ CISPR 22:2002- Class B, Electromagnetic Radiation, Terminal Disturbance Voltage.
EN61000-6-3:2001, Harmonic Current Emissions, Voltage fluctuations and Flicker.
TELECOM
TBR21, EU. PTC200, NEW ZEALAND TELECOM . AS ACIF S002, AUSTRALIA
SAFETY
EN60950:2000 inc Country Deviations, Safety of Information Technology Equipment
N55
NESS D8X / D16X PRODUCT RANGE
CONTROL PANEL PACKING LIST
1 D8x or D16x Main board
1 Housing
1 Keypad (LCD, Navigator or Saturn)
1 17VAC plug pack
1 12V 7Ah battery (optional)
1 Dialler telephone lead
1 User manual
1 Installer manual
9 or 17 End Of Line resistors 2.2k (D8x/D16x)
1 Lead assembly for battery
1 Lead assembly for internal tamper
1 Zone list label
2 Housing cover screws
4 Circuit board standoffs
AUSTRALIAN PRODUCT LIST
106-110 D8x PANEL inc NAVIGATOR Keypad
106-111 D8x PANEL KIT inc NAVIGATOR Keypad
KIT105 D8x PANEL inc SATURN Keypad - White
KIT104 D8x PANEL inc SATURN Keypad - Ocean Mist
KIT103 D8x PANEL inc SATURN Keypad - Black
106-001 D8x PANEL inc LCD Keypad
106-003 D8x PANEL KIT inc LCD Keypad
106-112 D16x PANEL inc NAVIGATOR Keypad
106-113 D16x PANEL KIT inc NAVIGATOR Keypad
KIT119 D16x PANEL inc SATURN Keypad - White
KIT112 D16x PANEL inc SATURN Keypad - Ocean Mist
KIT113 D16x PANEL inc SATURN Keypad - Black
106-004 D16x PANEL inc LCD Keypad
106-005 D16x PANEL KIT inc LCD Keypad
86
Ness D8x / D16x Control Panel – Installation Manual
