Ness D8X Installation & Programming Manual

AUX3 OUTPUT OPTIONS
Only one of the P123E options may be selected.
Option No. Description Default
P123E
1E [not used]
OFF
2E [not used]
OFF
3E
Enable AUX3 for AutoTimer
OFF
4E [not used]
OFF
5E [not used]
OFF
6E [not used]
OFF
7E [not used]
OFF
8E
Reader output pulses Aux3
OFF
P123E 1E-8E
AUX3 OUTPUT OPTIONS
PROGRAM MODE LEVEL
Installer mode or NessComms.
FACTORY DEFAULT
1E on.
NOTES
Only one option can be on. Turning an
option on turns off another.
RELATED OPTIONS
P143E 1E-8E Enhanced AUX3 options.
P374E 5E-6E AutoTimer1 AUX3 options.
P379E 5E-6E AutoTimer2 AUX3 options.
P384E 5E-6E AutoTimer3 AUX3 options.
P389E 5E-6E AutoTimer4 AUX3 options.
P123E is one of several options which control the behaviour of the AUX3 output.
One of the most powerful features of the D8x/D16x panels is the flexibility to control
the AUX outputs by various events and alarms. If the AUX3 output does not behave as
expected, please check all related options such as AutoTimers and P143E options.
TO PROGRAM
1. Press P123E.
2. Press 1E ... 8E to turn an option on. Only one option can be on.
P123E 3E
ENABLE AUX3 FOR AUTOTIMER
Available in D8x/D16x V6 and later.
RELATED OPTIONS
P370E to P389E. AutoTimers.
When this option is on, AUX3 is enabled for use by AutoTimer.
P123E 8E
READER OUTPUT TO AUX3
RELATED OPTIONS
P318E, P328E, P338E, P319E, P329E,
P339E.
This option enables an access control reader to pulse Aux3 when a valid access card is
presented. Set the reader using P318E, P328E or P338E.
Any or all of the P143E options may be selected.
Option No. Description Default
P143E
1E Area1 Armed to AUX3
OFF
2E Area2 Armed to AUX3
OFF
3E Home Mode arm to AUX3
OFF
4E Keypad toggle AUX3
OFF
5E Telephone remote control of AUX3
OFF
6E [not used]
OFF
7E [not used]
OFF
8E Pulse AUX3
OFF
62
Ness D8x / D16x Control Panel – Installation Manual
PROGRAMMING
