Ness D8X Installation & Programming Manual

AUX4 OUTPUT OPTIONS
Only one of the P124E options may be selected.
Option No. Description Default
P124E
1E [not used]
OFF
2E Enable Extension Sonalert
OFF
3E
Enable AUX4 for AutoTimer
OFF
4E [not used]
OFF
5E Enable AUX4 Fail To Communicate Output
OFF
6E [not used]
OFF
7E [not used]
OFF
8E
Reader output pulses AUX4
OFF
P124E 1E-8E
AUX4 OUTPUT OPTIONS
PROGRAM MODE LEVEL
Installer mode or NessComms.
FACTORY DEFAULT
1E on.
NOTES
Only one option can be on. Turning an
option on turns off another.
RELATED OPTIONS
P143E 1E-8E Enhanced AUX4 options.
P374E 5E-6E AutoTimer1 AUX4 options.
P379E 5E-6E AutoTimer2 AUX4 options.
P384E 5E-6E AutoTimer3 AUX4 options.
P389E 5E-6E AutoTimer4 AUX4 options.
P124E is one of several options which control the behaviour of the AUX4 output.
One of the most powerful features of the D8x/D16x panels is the flexibility to control
the AUX outputs by various events and alarms. If the AUX4 output does not behave as
expected, please check all related options such as AutoTimers and P144E options.
TO PROGRAM
1. Press P124E.
2. Press 1E ... 8E to turn an option on. Only one option can be on.
P124E 2E
ENABLE EXTENSION SONALERT
NOTES
The extension beeper can either be a
standard 12V sonalert or wire directly to the
Ness Quantum Sonic as shown. Keypad
beeps will be heard at low volume from the
Quantum Sonic's onboard siren. (Normal
siren sound is unaffected).
Enables the Aux4 output to duplicate all keypad beeps including keypress beeps. This is
useful in cases where, for example, entry beeps or other keypad beeps need to be heard in
more than one location on the premises. (Adding an additional keypad would also achieve
the same result).
P124E 3E
ENABLE AUX4 FOR AUTOTIMER
Available in D8x/D16x V6 and later.
RELATED OPTIONS
P370E to P389E. AutoTimers.
When this option is on, AUX4 is enabled for use by AutoTimer.
P124E 5E
ENABLE AUX4 FAIL TO COMMUNICATE OUTPUT
Available in D8x/D16x V6 and later.
RELATED OPTIONS
P370E to P389E. AutoTimers.
When this option is enabled AUX4 will turn on at the start of the fourth dialout attempt.
This can be used as Fail To Communicate output to trigger backup communications
devices such as GSM. The AUX4 output is automatically turned off on the next successful
communication attempt or when the panel is next disarmed.
P124E 8E
READER OUTPUT TO AUX4
RELATED OPTIONS
P318E, P328E, P338E, P319E, P329E,
P339E.
This option enables an access control reader to pulse AUX4 when a valid access card is
presented. Set the reader using P318E, P328E or P338E.
Any or all of the P144E options may be selected.
Option No. Description Default
P144E
1E Area1 Armed to AUX4
OFF
2E Area2 Armed to AUX4
OFF
3E Home Mode arm to AUX4
OFF
4E Keypad toggle AUX4
OFF
5E Telephone remote control of AUX4
OFF
6E [not used]
OFF
7E [not used]
OFF
8E Pulse AUX4
OFF
64
Ness D8x / D16x Control Panel – Installation Manual
