DAY ZONE FOLLOWER
This option allows Day zones to appear on the Zone Outputs.
In Day mode the Zone Output will follow the state of any active Day zone. This
occurs independently of the Program Zone selections P118E (Output Expander Zone
Follower) and P119E (Output Expander Zone Latch).
PROGRAMMING SEQUENCE:
P117E 3E toggles the option ON and OFF
OFF: No Day Zone Follower
ON: Day Zone Follower enabled
P117E 3E
PROGRAM MODE LEVEL
Installer mode or NessComms.
FACTORY DEFAULT
OFF: No Day Zone Follower.
NOTES
the D16 is in Home or Area modes.
OUTPUT EXCLUDE
This allows zones selected for Manual Exclusion (not Auto Exclusion) to also Exclude
the Expander Zone outputs. With this option ON, and if a zone has been manually
excluded then it will not signal an alarm on the Expander.
PROGRAMMING SEQUENCE:
P117E 4E toggles the option ON and OFF
OFF: No Output Exclude
ON: Output Exclude enabled
P117E 4E
PROGRAM MODE LEVEL
Installer mode or NessComms.
FACTORY DEFAULT
OFF: No Output Exclude.
OUTPUT EXPANDER ZONES
This selects the zones that will be output whenever the zone is unsealed. When the
zone reseals the output automatically goes off.
Additionally if a zone is also selected in P119 (to zone latch) then an output will only
occur whenever a zone is in alarm and is also unsealed. In this case when the zone
reseals the output automatically goes off again. A further zone unseal will turn the zone
Expander output On again.
PROGRAMMING SEQUENCE:
P118E 1E-16E toggles the options ON and OFF
[Zone No]E OFF: Output Expander disabled for that zone
[Zone No]E ON: Output Expander enabled for that zone
P118E
PROGRAM MODE LEVEL
Installer mode or NessComms.
FACTORY DEFAULT
All OFF: No Output Expander zones.
NOTES
options effectively gives pulsed outputs
whenever that zone alarms.
OUTPUT EXPANDER ALARM ZONES
This selects the zones that will be output whenever the zone is latched into alarm. The
output goes off only when the alarm system is reset.
Additionally if a zone is also selected in P118 (to zone follow) then an output will only
occur whenever a zone is in alarm and is also unsealed. (See P118 above).
PROGRAMMING SEQUENCE:
P119E 1E-16E toggles the option ON and OFF
[Zone No]E OFF: Output Expander zone alarm disabled for that zone
[Zone No]E ON: Output Expander zone alarm enabled for that zone
P119E
PROGRAM MODE LEVEL
Installer mode or NessComms.
FACTORY DEFAULT
OFF: No Output Expander zone latch.
ZONES 1–8 (D8 & D16) ZONES 9–16 (D16)
Option No. Description
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
P118 E OUTPUT EXPANDER ZONES
P119 E OUTPUT EXPANDER ALARM ZONES
55
Ness D8x / D16x Control Panel – Installation Manual
PROGRAMMING
