D8x/D16x V6 PROGRAMMING OPTIONS SUMMARY
Page 4 of 5
OPTION DESCRIPTION
DEFAULT
PAGE
P124E
2E Enable Extension Sonalert
OFF
64
3E
Enable AUX4 for AutoTime OFF
5E
Enable AUX4 as Fail To Communicate o/p
OFF
8E Reader [x] output to AUX4
OFF
P125E Enable hardwired zones
All on
66
P126E
1E KPX KP - Double key PANIC
ON
66
2E KPX KP - Double key FIRE
OFF
3E KPX KP - Double key MEDICAL
OFF
4E KPX KP - Entry Chime, DAY Mode
OFF
5E KPX KP - Entry Chime, HOME Mode
OFF
8E Disable One Digit At A Time display
ON
P129E
1E 0k EOL resistors
OFF
66
2E 1k EOL resistors
OFF
3E 1.5k EOL resistors
OFF
4E 2.2k EOL resistors
ON
5E 3.3k EOL resistors
OFF
6E 3.9k EOL resistors
OFF
7E 4.7k EOL resistors
OFF
8E 5.6k EOL resistors
OFF
9E 6.8k EOL resistors
OFF
10E 8.2k EOL resistors
OFF
11E 10k EOL resistors
OFF
12E 12k EOL resistors
OFF
13E 22k EOL resistors
OFF
P141E
1E Area 1 Armed to AUX1
OFF
59
2E Area 2 Armed to AUX1
OFF
3E Home Armed to AUX1
OFF
4E Keypad toggle AUX1
OFF
5E Telephone remote control of AUX1
OFF
6E [not used]
OFF
7E [not used]
OFF
8E Pulse AUX1
OFF
P142E
1E Area 1 Armed to AUX2
OFF
61
2E Area 2 Armed to AUX2
OFF
3E Home Armed to AUX2
OFF
4E Keypad toggle AUX2
OFF
5E Telephone remote control of AUX2
OFF
6E [not used]
OFF
7E [not used]
OFF
8E Pulse AUX2
OFF
P143E
1E Area 1 Armed to AUX3
OFF
63
2E Area 2 Armed to AUX3
OFF
3E Home Armed to AUX3
OFF
4E Keypad toggle AUX3
OFF
5E Telephone remote control of AUX3
OFF
6E [not used]
OFF
7E [not used]
OFF
8E Pulse AUX3
OFF
u
REAL TIME CLOCK options can be programmed in User Program Mode.
P340E Real Time Clock set MINUTES
00 (00-59)
68
P341E Real Time Clock set HOURS
00 (00-23)
P342E Real Time Clock set DAY
01 (01-31)
P343E Real Time Clock set MONTH
01 (01-12)
P344E Real Time Clock set YEAR
09 (00-63)
P345E Real Time Clock VIEW DAY OF WEEK
(Sun=1)
OPTION DESCRIPTION
DEFAULT
PAGE
P144E
1E Area 1 Armed to AUX4
OFF
65
2E Area 2 Armed to AUX4
OFF
3E Home Armed to AUX4
OFF
4E Keypad toggle AUX4
OFF
5E Telephone remote control of AUX4
OFF
6E [not used]
OFF
7E [not used]
OFF
8E Pulse AUX4
OFF
P145E
AUX1 Pulse Time (1-99 sec) 20 sec
59
P146E
AUX2 Pulse Time (1-99 sec) 20 sec
61
P147E
AUX3 Pulse Time (1-99 sec) 20 sec
63
P148E
AUX4 Pulse Time (1-99 sec) 20 sec
65
P199E Serial Output Options 1E-6E
All off
73
ACCESS CONTROL OPTIONS
P300E DEFAULT ALL ACCESS CONTROL OPTIONS
74
P301E
1E Use reader addresses
OFF
75
2E Arm with double read
ON
3E
Arm with single read and pushbutton
OFF
4E Disarm with access card
ON
5E
REX Input 1 (Zone 5 input)
OFF
6E
REX Input 2 (Zone 6 input)
OFF
7E
REX Input 3 (Zone 7 input)
OFF
8E
Strobe Flash on Arm/Disarm by Reader
ON
P303E DOTL zones
none
76
P304E DOTL time
20 sec
P305E
1E DOTL output LATCHES
OFF
2E DOTL outputs to Output Expander
OFF
3E
[not used]
4E
[not used]
5E DOTL zone flashes on keypad
OFF
AUX OUTPUTS
P318E
1E Ultraprox Reader1 to AUX1
OFF
77
2E Ultraprox Reader1 to AUX2
OFF
3E Ultraprox Reader1 to AUX3
OFF
4E Ultraprox Reader1 to AUX4
OFF
P319E Ultraprox Reader1 output TIME
5 sec
P328E
1E Ultraprox Reader2 to AUX1
OFF
2E Ultraprox Reader2 to AUX2
OFF
3E Ultraprox Reader2 to AUX3
OFF
4E Ultraprox Reader2 to AUX4
OFF
P329E Ultraprox Reader2 output TIME
5 sec
P338E
1E Ultraprox Reader3 to AUX1
OFF
2E Ultraprox Reader3 to AUX2
OFF
3E Ultraprox Reader3 to AUX3
OFF
4E Ultraprox Reader3 to AUX4
OFF
P339E Ultraprox Reader3 output TIME
5 sec
84
