NMC-Junior Pro Installation Manual
Page 53
Note: It is impossible to set the same Condition program for two different programs.
Rad Sum / VPD Sum: Choose whether irrigations can be triggered by the radiation or VPD sum. The
specific Rad Sum trigger is specified per period (see Rad Sum Li.
). ). If irrigation is not triggered due to
Rad/VPD Sum until Max time has elapsed irrigation will be performed due to Max time.
Note: When choosing Rad/VPD Sum the screen will be split in two. To view the day sequence, press the Down
arrow on the bottom part of the screen.
• Start time (hh:mm): ENTER up to six start times (periods) per day for each program.
• Clock Start: Set the number of time-based irrigation cycles that will be performed in this cycle. The first cycle
starts at the specified start time; subsequent cycles will start after the specified Min. Time.
• Cond. Starts (appears only when Cond. Is selected): On/Off.
On: Irrigations can be triggered by the Condition program, when the specified Condition program
settings are met (Condition program active).
Off: Irrigations will not be triggered by the condition program, regardless of the Condition program
status.
• Rad/VPD Sum Li.: Specify the radiation/VPD sum limit at which irrigation will take place. The Rad/VPD Sum
counter of the specific program is automatically reset when irrigation is performed. If Rad/VPD sum limit is '0'
it is ignored.
• Min. Time:
In Rad/VPD sum and condition modes determine the minimum time allowed between irrigations.
Even if the Rad/VPD sum limit / condition limit has been reached irrigation will not be performed until
that time has passed.
DATE : 1-May-12 TIME : 10:12:09
IRRIGATION PROGRAM
Clock Start
Rad Sum Li.
Min. Time
1
200
01:00
--
---
00:30
--
100
--:--
Run Time #
1
2 2
2
---
Screen 1 of 3 – In order to view the
DATE : 1-May-12 TIME : 10:12:09
IRRIGATION PROGRAM
Dose / Water
D - D W
D W
Screen 2 of 3 – In order to view the
