NETASQ U30 - Appendix D: Adding an Ng1000-A and Ng5000-A Extension Module; General Points

INSTALLATION GUIDE
APPENDIX D:
ADDING AN NG1000-A AND NG5000-A EXTENSION MODULE
APPENDIX D:
ADDING AN NG1000-A AND NG5000-A EXTENSION MODULE
The procedure for adding modules to the NG1000-A or NG5000-A firewall takes place in 5 main steps:
Step 1 Updating the product license.
Step 2 Downloading the license.
Step 3 Shutting down the firewall.
Step 4 Inserting the module.
Step 5 Restarting the firewall in console mode.
General points
Appliances concerned
NG1000-A and NG5000-A appliances.
NOTE
The maximum number of ports for the NG5000-A firewall is 22 ports.
Description of the cards
NG1000-A and NG5000-A appliances support the addition of one of the following extension
modules:
 4 * copper 1GbE ports (P/N: NA-NG-4GIG-C-E)
- RJ45
- IEEE 1000/100/10Base-T
 6 * copper 1GbE ports (P/N: NA-NG-6GIG-C-E)
- RJ45
- IEEE 1000/100/10Base-T
 2 * fiber 1GbE ports (P/N: NA-NG-2GIG-F-E)
- SFP
- Duplex LC
- IEEE 802.3z 1000BASE-SX
- Optical wavelength: 850nm
- Max fiber length: 550m on 50/125μm multimode fiber, 300m on 62.5/125μm multimode fiber
- Class 1 laser safety per EN (IEC) 60825 laser safety standards
 2 * fiber 1GbE ports (P/N: NA-NG-2GIG-F-L-E)
- SFP
- Duplex LC
- IEEE 802.3z 1000BASE-LX
- Optical wavelength: 1310nm
- Max fiber length: 10km on 9/125μm single mode fiber
- Class 1 laser safety per EN (IEC) 60825 laser safety standards
