Local Area Network – VLAN
Select VLAN to configure this service.
I T E M
D E F I N I T I O N
Select a LAN port
Select the port for use by the LAN.
Enable VLAN Mode
Select if you want to configure VLAN.
VLAN ID
Enter the VLAN ID..
Pbits
Enter a value from 0-7 indicating the priority bits that dictates the
priority of the VLAN.
Add button
Click to create an additional VLAN port.
Remove button
Select the  checkbox in the Remove column for each of the VLAN
setups you want to permanently delete and then click the Remove
button.
Apply/Save button
Click to save changes to your settings and refresh the current display.
