VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP – NF18ACV
UG01040 v 1.04 December 2018
Routing – Routing
The Routing – NAT page contains two sections Static Route and RIP Configuration
Static Route
The Static Route table displays a list of the configured static routes.
Click the Add or Delete buttons to add or remove static route definitions.
Enter the Destination Network Address or subnet mask.
Enter the Gateway IP Address and/or an available WAN Interface.
The Metric field is used to set a priority for this route, the lower the number the
higher the priority.
Select a Static Route row in the table and click the Delete button to permanently
delete that Static Route definition.
Click the Add button to create a new Static Route definition, see the Add Static
Route screen on right.
