VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP – NF18ACV
UG01040 v 1.04 December 2018
Wireless Advanced Settings – Advanced
On the Wireless Advanced Settings page select Advanced to access
the especially technical configuration settings of the wireless LAN interface.
Setting for two Channels: 2.4 GHz or 5 GHz
Select 2.4 GHz or 5 GHz to separately define the advanced wireless
settings for each wireless channel.
Once you have made the required changes and set the appropriate
parameters, click the Apply/Save button to save the changes for that
channel and restart the wireless connection.
Common and Specific Settings
While both channels share 22 common settings, there are other settings
which apply to only one channel or the other and there are other settings
which apply only when the 802.11n/EWC setting is Auto.
Shared Settings
See the Common Advanced Wireless Settings section for details on the
settings shared by both channels.
Extra settings when 802.11n/EWC set to ‘Auto’
For both channels when Auto is selected for the 802.11n/EWC setting ten
additional settings will appear on the Advanced settings page, refer to the
802.11n/EWS = Auto section, below.
Extra setting when 802.11n/EWC set to ‘Disabled’
For both channels when Disabled is selected for the 802.11n/EWC setting ten
additional settings will appear on the Advanced settings page, refer to the
802.11n/EWS = Disabled section, below.
Extra 2.4 GHz settings when 802.11n/EWC set to
‘Disabled’
When Disabled is selected for the 802.11n/EWC setting three additional settings
become available only for the 2.4 GHz channel, refer to the 2.4 GHz 802.11n/EWS
= Disabled section, below.
Extra 5 GHz settings
Regardless of the 802.11n/EWC setting, the 5GHz channel has six additional
settings, refer to Extra 5 GHz settings, below.
