Hardware Setup
8
N150 Wireless ADSL2+ Modem Router DGN1000
Hardware Features
Before you cable your router, take a moment to become familiar with the label and the front
and back panels. Pay particular attention to the LEDs on the front panel.
Label
The label on the bottom of the wireless modem router shows the router’s Restore Factory
Settings button, preset wireless information, MAC address, and serial number.
WiFi Network Name (SSID) WPA/WPA2-PSK Passphrase
Serial number MAC addressWPS PIN
Figure 2. Information on the router label
See Preset Security on page 32 for information about preset security and MAC addresses.
See Factory Settings on p
age 94 for information about the Restore Factory Settings button
and the factory setting values.
Restore Factory Settings button
Figure 3. Location of Restore Factory Settings button
