Chapter 3: Configuring Switching Information | 117
FS728TP Smart Switch Software Administration Manual
• Interface: Select Interface from the menu, enter the interface ID in e1, e2... format,
then, click Go. If any entries learned on that interface exist, they are displayed.
2. Click Clear to clear Dynamic MAC Addresses in the table.
3. Click Refresh to redisplay the page to show the latest MAC Addresses.
4. Click Cancel to cancel the configuration on the screen and reset the data on the screen to
the latest value of the switch.
The following table describes the information available for each entry in the address table.
Dynamic Address Configuration
Use the Dynamic Addresses page to set the amount of time to keep a learned MAC address
entry in the forwarding database. The forwarding database contains static entries, which are
never aged out, and dynamically learned entries, which are removed if they are not updated
within a given time.
To access the Configuration page, click Switching Address Table Advanced Dynamic
Addresses.
Field Description
VLAN ID Specifies the VLAN ID on which the IGMP Snooping Querier is
administratively enabled and for which VLAN exists in the VLAN database.
MAC Address A unicast MAC address for which the switch has forwarding and/or filtering
information. The format is a six-byte MAC address with each byte separated
by colons. For example, 00:0F:89:AB:CD:EF.
Interface The port where this address was learned: that is, this field displays the port
through which the MAC address can be reached.
Status The status of this entry. The possible values are:
• Static: The entry was added when a static MAC filter was defined.
• Learned: The entry was learned by observing the source MAC
addresses of incoming traffic, and is currently in use.
• Management: The system MAC address, which is identified with
interface c1.
