Appendix A: Hardware Specifications and Default Values | 232
A. Hardware Specifications and Default
Values
A
FS728TP Smart Switch Specifications
The FS728TP Smart Switch conforms to the TCP/IP, UDP, HTTP, ICMP, TFTP, DHCP, IEEE
802.1D, IEEE 802.1p, and IEEE 802.1Q standards.
Feature Value
Interfaces 24 10/100 Ethernet ports
Two 10/100/1000M Gigabit Ethernet (RJ-45) ports
Two 1000M Gigabit Ethernet combo ports
RJ-45 supports auto sensing for 10/100/1000M speed on RJ45
and 1000M on SFP1000M SFP Gigabit Ethernet ports
PoE Ports 1–24, IEEE 802.3af, Alternative A (MDI-X)
Flash memory size 16 MB
SRAM size and type 64 MB DDR
Feature Value
Switching capacity Non-Blocking Full WireSpeed on all packet sizes
Forwarding method Store and Forward
Packet forwarding rate 10M:14,880 pps/
100M:148,810 pps/
1G:1,488,000 pps
MAC addresses 4K
Green Ethernet Automatic power down on port when link is down
