Appendix A: Hardware Specifications and Default Values | 233
FS728TP Smart Switch Software Administration Manual
FS728TP Switch Features and Defaults
Feature Sets Supported Default
Auto negotiation/static
speed/duplex
All ports Auto negotiation
Auto MDI/MDIX N/A Enabled
802.3x flow control/back pressure 1 (per system) Disabled
Port mirroring 1 Disabled
Port trunking (aggregation) 8 Pre-configured
802.1D spanning tree 1 Disabled
802.1w RSTP 1 Disabled
802.1s spanning tree 3 instances Disabled
Static 802.1Q tagging 128 VID = 1
Member ports = 28
Learning process Supports Static and dynamic MAC
entries
Dynamic learning is enabled by
default
PoE 24 Enabled
Feature Sets Supported Default
Storm control All ports Disabled
Jumbo frame All ports Disabled
Max = 2032 bytes
Feature Sets Supported Default
Number of queues 8 N/A
Port based N/A N/A
802.1p 1 Enabled
DSCP 1 Disabled
Rate limiting All ports Disabled
Auto-QoS All ports Disabled
