182 | Chapter 5: Managing Device Security
FS728TP Smart Switch Software Administration Manual
• Source IP Address. Requires a packet’s source IP address to match the address
listed here. Type an IP Address in the appropriate field using dotted-decimal notation.
The address you enter is compared to a packet's source IP Address.
• Source IP Mask. Specifies the source IP address wildcard mask. Wild card masks
determines which bits are used and which bits are ignored. A wild card mask of
255.255.255.255 indicates that no bit is important. A wildcard of 0.0.0.0 indicates that
all of the bits are important. Wildcard masking for ACLs operates differently from a
subnet mask. A wildcard mask is in essence the inverse of a subnet mask. For
example, to apply the rule to all hosts in the 192.168.1.0/24 subnet, you type
0.0.0.255 in the Source IP Mask field. This field is required when you configure a
source IP address.
2. To delete an IP ACL rule, select the check box associated with the rule, and then click
Delete.
3. To update an IP ACL rule, select the check box associated with the rule, update the desired
fields, and then click Apply. You cannot modify the Rule ID of an existing IP rule.
4. Click Cancel to cancel the configuration on the screen and reset the data on the screen to
the latest value of the switch.
5. If you change any of the settings on the page, click Apply to send the updated configuration
to the switch. Configuration changes take effect immediately.
IP Extended Rule
Use the IP Extended Rules page to define rules for IP-based extended ACLs. The access list
definition includes rules that specify whether traffic matching the criteria is forwarded
normally or discarded.
Note: There is an implicit “deny all” rule at the end of an ACL list. This
means that if an ACL is applied to a packet and if none of the explicit
rules match, then the final implicit “deny all” rule applies and the
packet is dropped.
To display the IP extended Rules page, click Security ACL, then click the Advanced IP
Extended Rules link. In the following figure, an extended IP ACL exists, and one rule has
been configured.
