194 | Chapter 6: Monitoring the System
FS728TP Smart Switch Software Administration Manual
The following table describes the detailed port information displayed on the screen. To view
information about a different port, select the port number from the Interface menu.
Field Description
Interface Use the drop down menu to select the interface for which data is to be
displayed or configured.
MST ID Displays the created or existing MSTs.
ifIndex This field indicates the ifIndex of the interface table entry associated with this
port on an adapter.
Port Type For most ports this field is blank. Otherwise the possible values are:
• Mirrored: Indicates that the port has been configured as a monitoring port
and is the source port in a port mirroring session. For additional
information about port monitoring and probe ports, see
Multiple Port
Mirroring on page 211.
• Probe: Indicates that the port has been configured as a monitoring port
and is the destination port in a port mirroring session. For additional
information about port monitoring and probe ports, see
Multiple Port
Mirroring on page 211.
• Port Channel: Indicates that the port has been configured as a member
of a port-channel, which is also known as a link Aggregation Group (LAG).
