64 | Chapter 2: Configuring System Information
FS728TP Smart Switch Software Administration Manual
A popup window displays information for the selected port.
The following table describes the detailed local information that displays for the selected port.
Field Description
Managed Address
Address SubType Displays the type of address the management interface uses, such as an IPv4
address.
Address Displays the address used to manage the device.
Interface SubType Displays the port subtype.
Interface Number Displays the number that identifies the port.
MAC/PHY Details
Auto-Negotiation Supported Specifies whether the interface supports port-speed auto-negotiation. The
possible values are True or False.
Auto-Negotiation Enabled Displays the port speed auto-negotiation support status. The possible values
are True (enabled) or False (disabled).
Auto Negotiation Advertised
Capabilities
Displays the port speed auto-negotiation capabilities such as 1000BASE-T
half-duplex mode or 100BASE-TX full-duplex mode.
Operational MAU Type Displays the Medium Attachment Unit (MAU) type. The MAU performs
physical layer functions, including digital data conversion from the Ethernet
interface collision detection and bit injection into the network.
