ProSafe Gigabit 8 Port VPN Firewall FVS318G Reference Manual
5-18 Virtual Private Networking Using IPsec
1.1 November, 2009
• IPsec Host. If you want authentication by the remote gateway, enter a User Name and
Password to be associated with this IKE policy. If this option is chosen, the remote gateway
must specify the user name and password used for authenticating this gateway.
Configuring XAUTH for VPN Clients
Once the XAUTH has been enabled, you must establish user accounts on the User Database to be
authenticated against XAUTH, or you must enable a RADIUS-CHAP or RADIUS-PAP server.
To enable and configure XAUTH:
1. Select VPN > IPsec VPN from the main menu.
2. Click the IKE Policies tab. The IKE Policies screen is displayed.
3. You can add XAUTH to an existing IKE Policy by clicking Edit adjacent to the policy to be
modified or you can create a new IKE Policy incorporating XAUTH by clicking Add.
4. In the Extended Authentication section, choose the Authentication Type from the pull-
down menu which will be used to verify user account information. Select
Note: If a RADIUS-PAP server is enabled for authentication, XAUTH will first check the
local User Database for the user credentials. If the user account is not present, the
VPN firewall will then connect to a RADIUS server.
Note: You cannot modify an existing IKE policy to add XAUTH while the IKE policy is
in use by a VPN policy. The VPN policy must be disabled before you can modify
the IKE policy.
Figure 5-18
