ProSafe Gigabit 8 Port VPN Firewall FVS318G Reference Manual
3-10 LAN Configuration
1.1 November, 2009
To reserve an IP address, manually enter the device in the LAN Groups tab, specifying Reserved
(DHCP Client).
Configuring Multi Home LAN IP Addresses
If you have computers on your LAN using different IP address ranges (for example, 172.16.2.0 or
10.0.0.0), you can add “aliases” to the LAN port, giving computers on those networks access to the
Internet through the VPN firewall. This allows the VPN firewall to act as a gateway to additional
logical subnets on your LAN. You can assign the VPN firewall an IP address on each additional
logical subnet.
To add a secondary LAN IP address, follow these steps:
1. Select Network Configuration > LAN Settings from the main menu, and click the LAN
Multi-homing tab. The LAN Multi-homing screen displays.
The Available Secondary LAN IPs table lists the secondary LAN IP addresses added to the
VPN firewall.
• IP Address. The “alias,” an additional IP address hosted by the LAN port of the VPN
firewall. This address will be the gateway for computers on the secondary subnet.
• Subnet Mask. The IPv4 subnet mask that defines the range of the secondary subnet.
Note: The reserved address will not be assigned until the next time the PC contacts the
VPN firewall’s DHCP server. Reboot the PC or access its IP configuration and
force a DHCP release and renew.
Figure 3-4
