ProSafe Gigabit 8 Port VPN Firewall FVS318G Reference Manual
LAN Configuration 3-11
1.1 November, 2009
2. In the Add Secondary LAN IP Address section, enter the additional IP address and subnet
mask to be assigned to the LAN port of the VPN firewall.
3. Click Add. The new Secondary LAN IP address will appear in the Available Secondary LAN
IPs table.
Configuring Static Routes
Static Routes provide additional routing information to your VPN firewall. Under normal
circumstances, the VPN firewall has adequate routing information after it has been configured for
Internet access, and you do not need to configure additional static routes. You should configure
static routes only for unusual cases such as multiple firewalls or multiple IP subnets located on
your network.
To add or edit a static route:
1. Select Network Configuration > Routing from the main menu. The Routing screen displays.
Note: IP addresses on these secondary subnets cannot be configured in the DHCP
server. The hosts on the secondary subnets must be manually configured with
IP addresses, gateway IP addresses, and DNS server IP addresses.
Tip: The secondary LAN IP address will be assigned to the LAN interface of the
VPN firewall and can be used as a gateway by computers on the secondary
subnet.
Figure 3-5
