ProSafe Gigabit 8 Port VPN Firewall FVS318G Reference Manual
2-4 Connecting the FVS318G to the Internet
1.1 November, 2009
• Main menu. The horizontal orange bar near the top of the page is the main menu, containing
the primary configuration categories. Clicking on a primary category changes the contents of
the submenu bar.
• Submenu. The horizontal grey bar immediately below the main menu is the submenu,
containing subcategories of the currently selected primary category.
• Tab. Immediately below the submenu bar, at the top of the menu active window, are one or
more tabs, further subdividing the currently selected subcategory if necessary.
• Option arrow. To the right of the tabs on some menus are one or more blue dots with an arrow
in the center. Clicking an option arrow brings up either a popup window or an advanced option
menu.
You can now proceed to the first configuration task, configuring the VPN firewall’s Internet
connections.
Configuring the Internet Connections
To set up your VPN firewall for secure Internet connections, you configure the WAN port. The
Web Configuration Manager offers two connection configuration options:
• Automatic detection and configuration of the network connection.
• Manual configuration of the network connection.
Each option is detailed in the sections following.
Tip: In the instructions in this guide, we may refer to a menu using the notation
primary | subcategory, such as Network Configuration | WAN Settings. In this
example, Network is the selected primary category (in the main menu) and
WAN Settings is the selected subcategory (in the submenu).
