ProSafe Gigabit 8 Port VPN Firewall FVS318G Reference Manual
Connecting the FVS318G to the Internet 2-7
1.1 November, 2009
3. To verify the connection, click the Broadband Status option arrow at the top right of the
screen. A popup window appears, displaying the connection status of the WAN port.
The Connection Status window should show a valid IP address and gateway. If the
configuration was not successful, skip ahead to “Manually Configuring the Internet
Connection following this section, or see “Troubleshooting the ISP Connection” on page 8-4.
If your WAN ISP configuration was successful, you can skip ahead to “Configuring the WAN
Mode” on page 2-11.
If the automatic WAN ISP configuration failed, you can attempt a manual configuration as
described in the following section, or see “Troubleshooting the ISP Connection” on page 8-4.
Manually Configuring the Internet Connection
Unless your ISP automatically assigns your configuration automatically via DHCP, you will need
to obtain configuration parameters from your ISP in order to manually establish an Internet
connection. The necessary parameters for various connection types are listed in Table 2-1.
Figure 2-5
Note: If the configuration process was successful, you are connected to the Internet
through the WAN port.
