ProSafe Gigabit 8 Port VPN Firewall FVS318G Reference Manual
5-2 Virtual Private Networking Using IPsec
1.1 November, 2009
Creating Gateway to Gateway VPN Tunnels with the Wizard
Follow these steps to set up a gateway VPN tunnel using the VPN Wizard.
1. Select VPN > VPN Wizard to display the VPN Wizard tab page.
To view the wizard default settings, click the VPN Default values link. You can modify these
settings after completing the wizard.
2. Select Gateway as your connection type.
Figure 5-1
Figure 5-2
Gateway connection
Connection name
Pre-shared key
Remote and local WAN
addresses
Remote LAN IP address
and subnet

NETGEAR FVS318G - ProSafe Gigabit VPN Firewall Data Sheet Router Specifications

General

Model	FVS318G
Category	Network Router
VPN Tunnels	25
VPN Throughput	25 Mbps
VPN Protocols	IPSec, PPTP, L2TP
Humidity	90% maximum relative humidity, non-condensing
WAN Ports	1
LAN Ports	8
Weight	1.4 kg (3.1 lb)
Firewall Security	SPI, DoS
Flash Memory	8 MB
Operating Temperature	0° to 40°C
Storage Temperature	-20° to 70°C
