ProSafe Gigabit 8 Port VPN Firewall FVS318G Reference Manual
Virtual Private Networking Using IPsec 5-23
1.1 November, 2009
.
4. Enter a descriptive Record Name such as “Sales”.
5. Assign at least one range of IP Pool addresses in the First IP Pool field to give to remote VPN
clients.
6. If you have a WINS Server on your local network, enter its IP address.
7. Enter one or two DNS Server IP addresses to be used by remote VPN clients.
8. If you enable Perfect Forward Secrecy (PFS), choose DH Group 1 or 2. This setting must
match exactly the configuration of the remote VPN client,
9. Specify the Local IP Subnet to which the remote client will have access. Typically, this is your
VPN firewall’s LAN subnet, such as 192.168.2.1/255.255.255.0. (If not specified, it will
default to the LAN subnet of the VPN firewall.)
Figure 5-21
Note: The IP Pool should not be within your local network IP addresses. Use a
different range of private IP addresses such as 172.20.xx.xx.

NETGEAR FVS318G - ProSafe Gigabit VPN Firewall Data Sheet Router Specifications

General

Model	FVS318G
Category	Network Router
VPN Tunnels	25
VPN Throughput	25 Mbps
VPN Protocols	IPSec, PPTP, L2TP
Humidity	90% maximum relative humidity, non-condensing
WAN Ports	1
LAN Ports	8
Weight	1.4 kg (3.1 lb)
Firewall Security	SPI, DoS
Flash Memory	8 MB
Operating Temperature	0° to 40°C
Storage Temperature	-20° to 70°C
