Technical Specifications and Factory Default Settings A-1
1.1 November, 2009
Appendix A
Technical Specifications and Factory Default
Settings
You can use the reset button located on the front of your device to reset all settings to their factory
defaults. This is called a hard reset.
• To perform a hard reset, push and hold the reset button for approximately 5 seconds (until the
Test LED blinks rapidly). Your device will return to the factory configuration settings shown
in Table A-1 below.
• Pressing the reset button for a shorter period of time will simply cause your device to reboot.
Table A-1. Business Router Default Configuration Settings
Feature Default Behavior
Router Login
User Login URL http://192.168.1.1/index.htm
User Name (case sensitive) admin
Login Password (case sensitive) password
Internet Connection
WAN MAC Address Use Default address
WAN MTU Size 1500
Port Speed AutoSense
Local Network (LAN)
Lan IP 192.168.1.1
Subnet Mask 255.255.255.0
RIP Direction None
RIP Version Disabled
RIP Authentication None
DHCP Server Enabled
