NETGEAR FVS318G - ProSafe Gigabit VPN Firewall Data Sheet Router User Manual

ProSafe Gigabit 8 Port VPN Firewall FVS318G Reference Manual
Technical Specifications and Factory Default Settings A-3
1.1 November, 2009
This appendix provides technical specifications for the ProSafe VPN Firewall.
Table A-2. Technical Specificaions
Specification Description
Network Protocol and Standards Compatibility
Data and Routing Protocols: TCP/IP, RIP-1, RIP-2, DHCP
PPP over Ethernet (PPPoE)
Power Adapter
North America: 120V, 60 Hz, input
United Kingdom, Australia: 240V, 50 Hz, input
Europe: 230V, 50 Hz, input
Japan: 100V, 50/60 Hz, input
All regions (output): 12 V DC @ 1.5 A output, 18W maximum
Physical Specifications
Dimensions: 32 x 189 x 123 mm (1.6 x 10 x 7 in)
Weight: 590 g (1.3 lb)
Environmental Specifications
Operating temperature: 0 to 40 C (32º to 104º F)
Operating humidity: 90% maximum relative humidity, noncondensing
Electromagnetic Emissions
Meets requirements of: FCC Part 15 Class B
VCCI Class B
EN 55 022 (CISPR 22), Class B
Interface Specifications
LAN: Eight 10/100/1000BASE-Tx (Gb), RJ-45 ports
WAN: One 10/100/1000BASE-Tx (Gb), RJ-45 port

NETGEAR FVS318G - ProSafe Gigabit VPN Firewall Data Sheet Router Specifications

General

Model	FVS318G
Category	Network Router
VPN Tunnels	25
VPN Throughput	25 Mbps
VPN Protocols	IPSec, PPTP, L2TP
Humidity	90% maximum relative humidity, non-condensing
WAN Ports	1
LAN Ports	8
Weight	1.4 kg (3.1 lb)
Firewall Security	SPI, DoS
Flash Memory	8 MB
Operating Temperature	0° to 40°C
Storage Temperature	-20° to 70°C
