ProSafe Gigabit 8 Port VPN Firewall FVS318G Reference Manual
1-6 Introduction
1.1 November, 2009
The function of each LED is described in the following table:
Table 1-1. LED Descriptions
Object Activity Description
Power On (Green)
Off
Power is supplied to the VPN firewall.
Power is not supplied to the VPN firewall.
Test On (Amber)
Off
Test mode: The system is initializing or the initialization has failed.
The system has booted successfully.
WAN Port
Active (left
side of port)
On (Green)
Off)
The WAN port is connected.
The Internet connection is down The WAN port is either not enabled
or has no link.
Speed (right
side of port)
On (Green)
On (Amber)
Off
The port is operating at 1,000 Mbps.
The port is operating at 100 Mbps.
The port is operating at 10 Mbps.
LAN Ports
Link and
Activity(left
side of port)
On (Green)
Blinking (Green)
Off
The port has detected a link with a connected Ethernet device.
Data is being transmitted or received by the port.
The port has no link.
Speed (right
side of port)
On (Green)
On (Amber)
Off
The LAN port is operating at 1,000 Mbps.
The LAN port is operating at 100 Mbps.
The LAN port is operating at 10 Mbps.
DMZ On (Green)
Off
LAN port 8 is enabled as a DMZ port.
LAN port 8 is not enabled as a DMZ port.

NETGEAR FVS318G - ProSafe Gigabit VPN Firewall Data Sheet Router Specifications

General

Model	FVS318G
Category	Network Router
VPN Tunnels	25
VPN Throughput	25 Mbps
VPN Protocols	IPSec, PPTP, L2TP
Humidity	90% maximum relative humidity, non-condensing
WAN Ports	1
LAN Ports	8
Weight	1.4 kg (3.1 lb)
Firewall Security	SPI, DoS
Flash Memory	8 MB
Operating Temperature	0° to 40°C
Storage Temperature	-20° to 70°C
