NETGEAR R7000 User Manual

Specify Network Settings
137
Nighthawk AC1900 Smart WiFi Router
Use the Router as a Wireless Access Point
You can set up the router to run as an access point (AP) on the same local network as
another router or gateway.
 To set up the router as an AP after you set up your Internet:
1. Use an Ethernet cable to connect the Internet port of this router to a LAN port on your
existing router or gateway
.
Cable this port to a LAN port
on another router
2. Launch a web browser from a computer or WiFi device that is connected to the network.
3. Enter http://www
.routerlogin.net.
A login window displays.
4. Enter the router user name and password.
The user name is admin.
The default password is password. The user name and
password are case-sensitive.
The BASIC Home page displays.
5. Select ADV
ANCED > Advanced Setup > Wireless AP.
6. Select the Enable AP Mode check box.
7. Scroll down and select the radio button for the IP address setting that you want to use:

NETGEAR R7000 Specifications

General

Brand	NETGEAR
Model	R7000
WiFi Technology	802.11ac
USB Ports	1 x USB 3.0, 1 x USB 2.0
Antennas	3 external antennas
Beamforming	Yes
RAM	256 MB
Flash Memory	128 MB
Frequency Band	2.4 GHz / 5 GHz
WiFi Speed	Up to 1900 Mbps
Processor	1 GHz dual-core processor
Ethernet Ports	5 (1 WAN & 4 LAN)
Security	WPA/WPA2
Dimensions	285 x 184.5 x 50 mm (11.22 x 7.26 x 1.97 in)
Weight	750 g
