NETGEAR R7000 User Manual

Specify Your Internet Settings
44
Nighthawk AC1900 Smart WiFi Router
8. In the Name field, enter a name for the VLAN tag group.
The name can be up to 10 characters.
9. In the VLAN ID field, enter a value from 1 to 4094.
This value is provided by your Internet service provider.
10. In the Priority field, enter a value from 0 to 7.
This value is provided by your Internet service provider.
11. Select a Wired Ports check box or a Wireless check box:
• If your device is connected to an Ethernet port on the router, select a Wired Ports
check box that corresponds to the Ethernet port on the router to which the device is
connected.
• If your device is connected to your router’s WiFi network, select a Wireless check box
that corresponds to the router’s WiFi network to which the device is connected to.
Note: You must select at least one Wired Ports or Wireless check box. You
can select more than one check box.
12. Click the Add button.
The VLAN tag group is added.
13. Click the Apply button.
Your settings are saved.

NETGEAR R7000 Specifications

General

Brand	NETGEAR
Model	R7000
WiFi Technology	802.11ac
USB Ports	1 x USB 3.0, 1 x USB 2.0
Antennas	3 external antennas
Beamforming	Yes
RAM	256 MB
Flash Memory	128 MB
Frequency Band	2.4 GHz / 5 GHz
WiFi Speed	Up to 1900 Mbps
Processor	1 GHz dual-core processor
Ethernet Ports	5 (1 WAN & 4 LAN)
Security	WPA/WPA2
Dimensions	285 x 184.5 x 50 mm (11.22 x 7.26 x 1.97 in)
Weight	750 g
