Replace a Fan on a ReadyNAS 3220, 3312, 3312 v2, 4220,
4312, or 4312 v2
To replace a fan on a ReadyNAS 3220, 3312, 3312 v2, 4220, 4312, or 4312 v2
storage system:
1. Remove the chassis cover.
For more information, see Access the Inside of the Storage System on page 98.
2.
Disconnect the fan's power connections.
3.
Squeeze the latches on top of the fan and pull up gently to remove the fan from the
housing.
4.
Insert the replacement fan into the housing.
5.
Connect the replacement fan's power connections.
If the system power is on, the hot-plug feature causes the fan to start immediately.
Hardware Manual104Maintenance
ReadyNAS OS 6
