NETGEAR ReadyNAS 3220

8. One display port
9. One micro USB console connector (marked UART)
Status Information
You can obtain information about the status of your system by reviewing the indicators
listed in the following table.
Table 2. Status indicators
DescriptionIndicator
The Power LED indicates these states:
•
Green. The system is powered on.
•
Blinking. The system is powering on or powering off.
•
Off. Power is not supplied to the system.
Power LED (control panel)
The UI (Unit Identification) LED indicates these states:
•
Blue. Software or manual identification is on.
•
Off. Identification is not requested by software or manually when the UI button
is pressed.
Pressing the UI button on either the control panel or the rear panel toggles the
UI LEDs on the control panel and the rear panel. Use this in a situation such as a
densely populated rack when you are working from both the front and back of
the server.
UI LED (control panel)
The Health LED indicates these states:
•
Red. The system needs attention. Use the local admin page to determine the
problem. For more information, see the ReadyNAS OS 6.5 Software Manual, which
is available at http://support.netgear.com/product/ReadyNAS-OS6.
•
Off. The system is healthy.
Health LED (control panel)
The LAN LED indicates these states:
•
Blue. One or more Ethernet ports are linked.
•
Blinking. One or more Ethernet ports are active.
•
Off. There is no Ethernet connection.
LAN LED (control panel)
