Monitoring
160
XS728T ProSAFE 28-Port 10-Gigabit L2+ Smart Switch
To modify the settings for an existing host, select the check box next to the host, change the
desired information, and click Apply.
Trap Logs
Use the Trap Logs screen to view information about the SNMP traps generated on the
switch.
To view SNMP traps:
Select Monitoring > Logs > Trap Logs.
The Number of Traps Since Last Reset field is displayed.
Note: Check the detailed contents of the reported traps through the SNMP
trap server. This action is not within the scope of this guide.
Port Mirroring
The screen you access from the Mirroring menu enables you to view and configure port
mirroring on the system.
Port mirroring selects the network traffic for analysis by a network analyzer. This is done for
specific ports of the switch. As such, many switch ports are configured as source ports, and
one switch port is configured as a destination port. You can configure how traffic is mirrored
on a source port. Packets that are received on the source port, that are transmitted on a port,
or are both received and transmitted, can be mirrored to the destination port.
The packet that is copied to the destination port is in the same format as the original packet
on the wire. This means that if the mirror is copying a received packet, the copied packet is
VLAN tagged or untagged as it was received on the source port. If the mirror is copying a
transmitted packet, the copied packet is VLAN tagged or untagged as it is being transmitted
on the source port.
You can mirror up to eight ports to a single destination port.
To configure port mirroring:
1. Select Monitoring > Port Mirroring.
2. Select the check box next to a port to configure it as a source port, or enter its name in the
Go To Interface field and click Go.
3. From the Destination Port list, select the port to which port traffic is to be copied. Use the
xg1, xg2,... format to specify the port. You can configure only one destination port on the
system.
4. From the Session Mode list, select the mode for port mirroring on the selected port:
