System
17
XS728T ProSAFE 28-Port 10-Gigabit L2+ Smart Switch
System CPU Status
Use this screen to view system RAM memory information and CPU utilization.
To enable CPU utilization:
1. Select System > Management > System CPU Status.
The following fields are displayed:
• Total System Memory. Amount of total RAM memory available on the device.
• Available Memory. Amount of unused RAM memory on the device.
2. Configure the following fields to enable or disable calculation of the CPU utilization:
• CPU Utilization. Select Disable or Enable. The default value is Enable.
• Refresh Rate. Select the number of seconds indicating how frequently CPU
utilization will be computed.
The CPU Input Rate, which is the number of frames forwarded to CPU per second, is
displayed.
The CPU Utilization Rate, which is the number of frames forwarded to CPU per second
is displayed in a graph at the bottom of the page. The number of values displayed on the
x axis is correlated to the refresh rate.
USB Device Information
Use this screen to view the files on the external USB Memory device, connected to the
device via USB port on device front panel.
Supported USB disks must:
• Comply with USB 2.0.
• Support file type of FAT32.
System Up Time Displays the number of days, hours, minutes and seconds since the last
system restart.
Base MAC Address Universally assigned network address.
IC Temp (C) Integrated circuit temperature in Celsius values.
Fan Status for Fans 1-4 The status of fan operations.
Model Name The model name of the switch.
Boot Version The boot code version of the switch.
Software Version The software version of the switch.
Field Description
