HX4E/MX8A Series Voice Gateway User Manual
New Rock Technologies, Inc. 15
Indicator
Status
Description
interface address fails to be acquired by using DHCP, the IP
addresses are conflicted, and the PPPoE dialing fails.
Red flashing
The device is starting or the Kupdate is upgrading.
Steady green
Registration is successful.
Blinking
alternatively
between red and
green
Registration is failed.
Green flashing
Calling.
Off
Registration has not started.
WAN
(green)
Steady green
A WAN connection is established without any service flow.
Green flashing
A WAN connection is established with service flow.
Off
WAN interface is disconnected.
AUX
(green)
Steady green
A link is connected without any service flow.
Green flashing
A service flow is being transmitted.
Off
A link is not connected.
VOICE
(Green-FXS,
yellow-FXO)
Indicates line type and device status:
Yellow flashing
The device is starting and the port is an FXO port.
Green flashing
The device is starting and the port is an FXS port.
Off
No line is detected. Possibly the voice interface card is not
inserted or the port is damaged.
Indicates running status:
Steady yellow
Calling in or out via an analog trunk.
Yellow flashing
Ringing of calling in for an analog trunk.
Steady green
Off-hook or call established
Green flashing
Ringing on incoming call
Off
The port is in idle status
Note: The device starts up for approximate 30s to indicate line type, then indicates
running status.
Indicator of button:
RST
To restore the MX8A to factory default, press the RST for more than 3 seconds and
release it when STU turn blinking red. This setting will be valid after rebooting the
device.
