User Manual HX4E/MX8A Series Voice Gateway
14 www.newrocktech.com
Figure 1-4 MX8A Back Panel
Table 1-9 Description of MX8A BackPanel
The console port is used for local management and testing. PCs can be connected to device by
linking the RS232 port to CON port.
Connecting cables need to be produced or purchased.
If the connection is established between the device and the mobile PC with no RS232 ports,
please use the cable together with a USB to an RS232 converter cable.
Cables are shown below in Figure 1-5 and Figure 1-6.
Auxiliary management interface
Figure 1-5 RJ45 to RS232 Serial Cable
Figure 1-6 USB to RS232 Converter
Cable
Table 1-10 Indicator Status of MX8A
The device is powered off or a power supply fault occurs.
The WAN interface does not acquire the IP address. Possibly the
WAN interface is not connected to a network cable, the WAN
