User Manual HX4E/MX8A Series Voice Gateway
34 www.newrocktech.com
Select if the gateway is required to automatically dial out the hotline number after
offhook. By default, hot line is disabled.
Disable hot line: close this feature.
Hot line: automatically dial out the hotline number after offhook.
Delay mode: automatically dial out the hotline number when the offhook is timeout
with a time delay of 5 seconds.
CRBT(Color
ring back tone)
Select it to activate CRBT (Color Ring Back Tone), and choose an audio file as ring back
tone.
There are two.dat files in the G.729 coding format (fring1.dat and fring2.dat) storage in
MX for factory default. You can upload .wav files through the Web GUI, for details, see
2.7.10 Greeting.
Select if the Speed dials is activated on this line. By default, this is not selected.
Use "Abbreviated number-Phone number", such as 20-13812345678.
Use a forward slash "/" to separate each group of abbreviated numbers.
The abbreviated numbers range from 20 to 49.
A maximum of 399 bytes can be configured.
Select if Call forwarding is activated on this line. By default, it is not selected.
All incoming calls are forwarded to the telephone number specified in this parameter.
All incoming calls are forwarded to the telephone number specified in this parameter
when they are not answered.
All incoming calls are forwarded to the telephone number specified in this parameter
when the extension is busy.
Select to activate call forking. Forking allows the device to initiate a call to another
telephone terminal while ringing on this line terminal. Either terminal may answer,
terminating ringing on the other terminal.
Release
control by
caller
Select if the call release is controlled by the caller. By default, this is not selected.
Selected: the gateway will immediately release the call upon caller hanging up; the
gateway will not release the call after the called party hanging up as long as the caller is
still off-hook until timeout (60 seconds by default);
Unselected: the gateway will immediately release the call upon either party hanging up
the call.
Select it only if the trunk of the PBX supports loop open signaling, in which
the PBX takes the loop open as the indication of disconnection. Select it only if the trunk
of the PBX supports loop open signaling, in which
the PBX takes the loop open as the indication of disconnection.
Note: Loop open interval can be configured on the Advanced > Line page.
If this item is selected, the Fax over IP label carried in INVITE is supported.
If a received INVITE message carries From and P-Asserted-Id header fields, the caller
identification number will be selected according to this parameter.
If the received INVITE message does not carry the P-Asserted-Id header field, caller
identification numbers are obtained from the From header field.
P-Asserted-Id field preferentially: The caller identification information is
preferentially obtained from the P-Asserted-Id field in the INVITE message.
From field only: The caller identification information is obtained from the From field
in the INVITE message.
From field only is selected by default.
