OM Series IP Telephony System Administrator Manual
www.newrocktech.com 6-7
Item Description
Min. jitter buffer
Used to reduce the impact of network jitter.
Max. jitter buffer
RTP drop SID
If it is selected the received RTP SID voice packets will be discarded. By default, SID
voice packets will not be dropped.
RTP destination address
This parameter specifies how to obtain the IP address of the receiving side for RTP
packets. By default, the IP address is obtained “From SDP global connection”.
From SDP global connection: obtain the IP address from SDP global connection;
From SDP media connection: obtain the IP address from SDP media description.
6.9 SIP Related Advanced Settings
Go to the Advanced > SIP page to configure advanced SIP parameters.
Figure 6-12 SIP related advanced setting interface
6.10 Dial Number Detection and Digit Map
A digit map consists of a set of digit strings, called rules, which describe the dialing plan of the device.
During the process of collecting DTMF digits, the device matches the receiving digit string with the rules
in the digit map. The receiving process is completed when a match situation is encountered. A well
defined digit map helps to speed up the call setup.
Go to the System > Dialing page seen in Figure 6-13.
It is recommended to use
the default values of SIP
parameters.
These two items are used
when the soft switch is IMS
