Figure 6-13 Dialing interface
A digit map in the device is composed with up to sixty rules each with up to 32 digits, and the total length
of a digit map is limited to 2280 digits. The rules in the factory default digit map covers the dialing
patterns of feature keys, such as *30, and others. The syntax of digit map is illustrated as below.
Table 6-2 Description of Digit map
Character Description
0-9, *, #
Match to specific a DTMF signal.
x
Match to any 1-digit DTMF signal. E.g.: x can be matched to 1 or 2.
.
Match to any string of DTMF signals.
T
End of collecting DTMF digits after timeout of waiting for next digit
[ ]
Match to a set of DTMF digits. For example,[1-3，5，7-9] means the set of 1, 2, 3, 5, 7, 8 and 9.
x.T
Match to a string a DTMF string with any length, and the ending is triggered by the timeout of
waiting for the next digit
x.#
Match to a DTMF string with any length ended with #
[2-8]xxxxxxx
Match to an 8-digit string starting with of any number between 2 and 8
02xxxxxxxxx
Match to an 11-digit string starting with 02
013xxxxxxxxx
Match to a 12-digit string starting with 013
13xxxxxxxxx
Match to an 11-digit string starting with 13
11x
Match to a 3-digit string starting with 11
9xxxx
Match to a 5-digit string starting with 9
6.11 Feature Codes
Go to the System > Feature codes page seen in Figure 6-14.
Click the icon to display the Digit map interface.
