Administrator Manual OM Series IP Telephony System
8-4 www.newrocktech.com
Figure 8-4 SIP phone configuration interface
While configuring IP extension, please enable G.729 codec and select the same DTMF
transmission mode written on interface of Advanced > System.
After configuration, go to the Basic > Status page to check the status of IP extension.
Enter IP extension
number and password.
Input IP address of
OM followed by
default port number
5060.
