LBP2 User Guide Document No: 50306-001 Rev G 3/12/2020 Page 42
2.6.3 Results Options
Each results item has its own dropdown list of results options as well as the drag
and drop feature. The Edit Pass/Fail and Display Options will open another
dialog box that contains additional choices. Only the Display Options and
Statistics for an item that has been dropped in a separate display can be
controlled separate from the Results window.
2.6.3.1 Display Options
The font size, color, and display notation for results can be changed using the
Display Options dialog box. Right-click a results item and select Display
Options to open the dialog box. The Display Options can be changed for all
results at once by clicking at the top of the Results window.
Set the font size, color, and the number of decimal places to be displayed for
the selected result. Scientific notation for the result can also be
enabled/disabled.
Note: If a pass/fail value is also enabled for the selected result item, the pass/fail
colors will overwrite the color selected here.
If an item has been dropped in a different display, the set display options are
maintained. The display options can also be changed for the results after
dropping it in a separate display area.
2.6.3.2 Individual Statistics
Statistics values can be enabled/disabled for each result individually. Right-
click on the heading of a result to view the options and select the statistics
values.
