28
6
Inserting the placeholder/emboss contrast slider
I
Emboss contrast slider
Placeholder
Illustration 008: NIB610/NIB620 - Inserting the placeholder/emboss contrast slider.
If not already placed, insert the placeholder or the emboss contrast slider into the
appropriate slider slot (I).
Placeholder is included in delivery.
Emboss contrast slider is part of the kit for emboss contrast. The kit can be ordered
as an accessory.
5
Inserting the eyepieces
III
II
I
Illustration 007: NIB610/NIB620 - Inserting the eyepieces.
Remove the black protective caps (I) from the eyepiece sleeves (II).
Press eyepieces (III) gently into the eyepiece sleeves.
NIB610/NIB620
3
