3.4. Start-Up and explanation of the components
3.4.1. Setting up power supply and commissioning
Setting up power supply
1
3
4
2
5
6
NIB610
NIB620
Illustration 010: NIB610/NIB620 - Setting up power supply and commissioning.
Connect the cold-device plug (1) to a suitable mains in (2) on the back of the microscope.
Insert the main power plug (3) into the power socket (4).
Switch on the device by setting the power switch (5) to position I on the left side.
The green LED power light (6) on the front of the microscope indicates commissioning.
Make sure the supplied voltage matches the instruments specifications:
100-240 V, 50/60 Hz.
To avoid electric shock, connect the cold-device plug to a properly grounded pow-
er socket. These cold-device plug has three-pin plugs to ensure proper grounding.
Cables and cords are vulnerable when bent or twisted. Never subject them to
excessive force.
